Single Phase - EATON 5PX 1000VA - 3000VA

The Eaton 5PX Rack/Tower UPS provides line-interactive backup power and scalable runtimes for servers, storage systems, VoIP gear and network equipment. With a next-generation intuitive LCD display, energy consumption metering down to the outlet group level, and up to 99% efficiency, the 5PX is the perfect UPS to protect modern IT equipment.

Eaton 5PX UPS - Technical Specifications

Product Snapshot
Power Rating	1500-3000 VA
Voltage	240 Vac
Frequency	50/60 Hz
Configuration	Rack/Tower
Product Series	Premier

UPS Models
Part Number	Power Rating	Input Plug	Output Receptacles
	(VA/Watts)
Eaton 5PX
5PX1500iRT	1500 / 1350	C14	(8) C13
5PX2000iRT	2000 / 1800	C14	(8) C13
5PX2200iRTAU	2200 / 1980	C20	(8) C13, (1) C19
5PX3000iRT2U	3000 / 2700	C20	(8) C13, (1) C19
Eaton 5PX 3U
5PX3000iRT3UAU	3000 / 2700	C20	(8) C13, (1) C19

Eaton 5PX UPS - Features

• Energy consumption metering down to the outlet group level
• Intuitive LCD screen displays all the information you need in one glance
• 5PX can provide up to 99% efficiency, reducing cooling and utility costs
• Delivered with Eaton’s Intelligent Power Software compatible with all major OS including virtualization software
• 0.9 power factor to protect more servers from one UPS
• Protects you with a three-year warranty on electronics (2 years on batteries)
